Product details

More Information

Product Features
• Duo layer 18” Beyma driver
• Tough-Tone paint finish
• Integral side and back 3-point rigging system
• Premium Baltic birch construction
• .gll files available for download
• Presets for DP-F / DP-N amps + SC-48FIR
• Versatile and practical
• Use in conjunction with the 21” sub for infrabass
AND punch
• EASE .gll files available for download

Technical Specifications


Specifications
Design Subwoofer
System Type 18" Subwoofer
Configuration Single Subwoofer
Frequency Response (+/-3 dB) 35 Hz - 100 Hz
Frequency Range (- 10 dB) 28 Hz - 125 Hz
Sensitivity 2.83 V / 1 m 103 dB*
Calculated Maximum SPL @ 1 m 141 dB*
System Peak SPL 147 dB**
System Rated Impedance 4 Ω
*
level at 1 m under half space conditions
using pink noise with crest factor 2,
with dedicated preset.
**
level at 1 m under half space conditions
using pink noise with crest factor 4,
with dedicated preset.
Low Frequency Transducer
Size 420 mm / 18"
Voice Coil Size 101.6 mm / 4.0" QUATTRO (4 layers)
LF Frame Material Aluminium
Model Name WLA-118SUB
Special Features
Aluminium demodulating ring
Waterproof
Power(AES2)
Enclosure
Dimensions - Unpacked:
Dimensions - Packed:
Weight
LF cone
Malt Cross® TCS
System Continuous Power (W) 1600
System Programme Power (W) 3200
System Peak Power (W) 6400
Crossover Frequency 100 Hz
20 Hz
Input Connector 2 x speakON compatible
Rigging & Hardware: 3 points for rigging
Vertical Splay angle range: /
Horizontal Splay angle /
Optional Accessories WLA-1 Common Fly Frame
Optional Accessories -
Stand pole: M20 Pole mount
Handles: 2 side 2 pcs)
Cabinet Type Rectangular
Enclosure Material and finish 18 mm plywood / Tough-Tone
Colour Black paint
Grille Material & Finish Powder coated perforated steel
Height Front 535 mm / 21.1"
Height Rear /
Width 566 mm / 23.4"
Depth 760 mm / 29.9"
Height 630 mm / 24.8"
Width Front /
Width Rear 656 mm / 25.8"
Depth 850 mm / 33.5"
Net Weight 57.8Kg / 127.2 lbs
Gross Weight 69.0Kg / 151.8 lbs
