Product details

More Information

With a 4.0″ LF driver voice coil and a 2.87″ high-frequency voice coil, WLA-112A delivers 680 W continuous and 1360 W peak power with a maximum SPL of 133 dB @ 1 m. Built from premium birch plywood and equipped with integral rigging, it’s a powerful, refined and ready-to-fly active array solution for professional touring and installation environments.

Technical Specifications
  • System Type: Active 12" coaxial Bi-Amplified.
  • Frequency Response (+/-3 dB): 55 Hz – 20 kHz.
  • Frequency Range (-10 dB): 35 Hz – 25 kHz.
  • Maximum SPL: 133 dB (Calculated @ 1m); 139 dB System Peak.
  • Nominal Coverage (H x V): 100° x 20°.
  • LF: 12" Beyma with a 4.0" voice coil.
  • HF: 1.5" exit Beyma compression driver with a 2.87" voice coil.
    Amplifier Design: Class D.
  • Power Rating: 680 W Continuous (600 W LF + 80 W HF); 1360 W Peak.
  • DSP: Internal DSP with 8 selectable FIR presets for phase-coherent response.
  • Connectivity:Input: Balanced XLR.Link: Balanced XLR pin.Network: RJ45 (RS485) for remote software control.Update: USB Type B
