PROGRAMME-X205T is a dual 5″ passive loudspeaker from our PROGRAMME-X Series, designed for high-quality distributed audio systems operating on 70 V / 100 V lines.

Enquire Now

Product details

More Information

Equipped with low-distortion internal transformers and dual LF drivers, PROGRAMME-X205T delivers increased SPL, improved dispersion, and the refined acoustic performance that defines the updated PROGRAMME-X range. Its 90° x 60° coverage ensures clear, consistent sound for a variety of commercial and hospitality environments.

Installation is simple and flexible — PROGRAMME-X205T includes 18 M8 rigging points and a U-bracket for fast wall or ceiling mounting. Finished in black or white, it integrates seamlessly into any architectural setting while offering durability and long-term reliability.

Selectable 70 V taps (15 / 30 / 60 / 120 W) and 100 V taps (30 / 60 / 120 W) provide installation flexibility, while operation at 8 Ω is also possible. Handling 100 W continuous (400 W peak) power, PROGRAMME-X205T combines clarity, control, and adaptability for modern fixed audio installations.

Technical Specifications

Speaker Specifications System & Power

  • System Type: Full-Range
  • Configuration: 2-way
  • System Continuous Power: 100 W
  • System Programme Power: 200 W
  • System Peak Power: 400 W

Performance

  • Max SPL @ 1m: 120 dB
  • Freq Response (+/-3 dB): 70 Hz - 20 kHz
  • Freq Range (-10 dB): 65 Hz - 20 kHz

Connectivity & Build

  • Bluetooth: No
  • IP Certification: None
  • Driver Brand: Wharfedale Pro

Low Frequency (LF) Driver

  • LF Driver Size: 2 x 5"
  • LF Voice Coil Size: 1"
  • LF Rated Impedance: 8 Ω
  • LF Power (RE:AES2-2012): 2 x 50 W

High Frequency (HF) Driver

  • HF Driver Type: Compression Driver
  • HF Voice Coil Size: 1"
  • HF Diaphragm Material: Rugged Phenolic
  • HF Exit Size: 1"
  • HF Power (RE:AES2-2012): 20 W
  • HF Rated Impedance: 8 Ω
    Preset Library: No

Input Connector: Barrier Strip

Waveguide Type: Square

Enclosure Material: MDF

Grille Material and Finish: Steel Black or White

Finish: Black or White

Handles: No

Deployment: Wall Mount, Flying

Pole Mount: None

Brackets Included: Yes

Rigging: Yes

M8: 18

Nominal Coverage (H x V): 90° x 60°

Sensitivity 2.83v / 1m: 94 dB

System Rated Impedance: 8 Ω

Crossover Frequency: 2.0 kHz

Recommended HPF = BW 18 dB/OCT.: 65 Hz

Transformer (T): Yes

Transformer Taps (70 V): 15 / 30 / 60 / 120 W

Transformer Taps (100 V): 30 / 60 / 120 W

Input Connectors (T): Barrier Strip
