WHARFEDALE PRO PROGRAMME-108T
WHARFEDALE PRO PROGRAMME-108T
WHARFEDALE PRO PROGRAMME-108T
WHARFEDALE PRO PROGRAMME-108T

WHARFEDALE PRO PROGRAMME-108T

8.0″ 2-way passive
1.0″ titanium done HF
M8 x 18
150 watts AES (RMS)
300 watts Programme
600 watts Peak
70 V Taps : 15/30/60/120 W
100 V Taps : 30/60/120 W
118 dB Max SPL @ 1 meter

Enquire Now

Product details

Technical Specifications
  • Active or Passive: Passive
  • System Type: Full-Range
  • Configuration: 2-way
  • System Continuous Power: 150 W
  • System Programme Power: 300 W
  • System Peak Power: 600 W
  • Max SPL @ 1m: 118 dB
  • Freq Response (+/-3 dB): 60 Hz – 20 kHz
  • Freq Range (-10 dB): 55 Hz – 20 kHz
  • Bi-amp Mode Switch: No
  • Bluetooth: No
  • IP Certification: None
  • Driver Brand: Wharfedale Pro
  • LF Driver Size: 8"
  • LF Voice Coil Size: 2"
  • LF Rated Impedance: 8 Ω
  • LF Power (RE:AES2-2012): 150 W
  • HF Driver Type: Compression Driver
  • HF Voice Coil Size: 1"
    HF Diaphragm Material: Titanium
    HF Exit Size: 1"
    HF Power (RE:AES2-2012): 15 W
    HF Rated Impedance: 8 Ω
    Input Connector: 2 x NL4 + Barrier Strip
    Waveguide Type: Rounded
    Enclosure Material: MDF
    Grille Material and Finish: Steel
    Finish: Black or White
    Deployment: Wall Mount, Flying
    Pole Mount: None
    Brackets Included: Yes
    Rigging: Yes
    M8: 18
    Nominal Coverage (H x V): 60° x 60°
    Sensitivity 2.83v / 1m: 90 dB
    System Rated Impedance: 8 Ω
    Crossover Frequency: 2.3 KHz
    Recommended HPF = BW 18 dB/OCT.: 55 Hz
    Transformer (T): Yes
    Transformer Taps (70 V): 15 / 30 / 60 / 120 W
    Transformer Taps (100 V): 30 / 60 / 120 W
    Included Accessory: Wall Bracket, User Manual
