Stable down to 2 Ohms and with huge Class D power, the DP-4100F is a 4-channel amplifier from our DP-F Series, designed for professional live sound and installation systems demanding high power, precision DSP control and absolute reliability.

Delivering 1000 W per channel at 8 Ω, 1700 W at 4 Ω and up to 5780 W bridged at 4 Ω, it offers exceptional output with low distortion and high efficiency. The latest DP-F models feature upgraded DSP controller software, expanded internal processing, an IPS colour display, locking XLR connectors and AES/EBU digital inputs — all enhancing system flexibility and user control.

Enquire Now

Product details

More Information

The  DSP Controller software provides powerful functionality for both DP-F and DP-N Series amplifiers. It offers amp grouping, precise EQ and level control, and access to a comprehensive preset library. With built-in SMAART API compatibility, it integrates seamlessly with leading system analysis tools for fast, efficient tuning and optimisation.. Available to download below.

Supporting 70 V Hi-Z operation, DP-4100F is ideal for large distributed installations or multi-zone configurations. Compact, efficient and powerful, it’s built for professionals who need consistent, accurate performance with next-generation control.

Technical Specifications

Power Output(Measured at THD=1%, 1 kHz, all channels driven simultaneously)

  • 8Ω Stereo: 4 x 1000 W
  • 4Ω Stereo: 4 x 1700 W
  • 2Ω Stereo: 4 x 2890 W
  • 16Ω Bridged: 2 x 2000 W
  • 8Ω Bridged: 2 x 3400 W
  • 4Ω Bridged: 2 x 5780 W
  • 70V Hi-Z: 4 x 1700 W

Audio Performance

  • DSP/Network: Internal DSP with FIR filtering; Dual Ethernet for remote control.
  • SNR/THD: $\geq$105 dB (20 Hz–20 kHz); 0.05% THD+N (10% rated power).
  • Frequency Response: +0, -0.5 dB (20 Hz – 20 kHz).
