Product details

More Information
Features
  • Up to 137 dB Sound Pressure Level
  • 4400W Class-D Bi-Amplification
  • 30-120 Hz linear frequency response
  • 2 x 18" High Power Woofers
  • IP Rated Powercon TRUE1 TOP IN/OUT
  • 8 Crossover Presets and 4 Cardioid Presets
Technical Specifications


TECHNICAL SPECIFICATIONS
Acoustical specifications Frequency Response 30 Hz - 120 Hz
Max SPL @ 1m 137 dB
Transducers Woofer 2 x 18'', 4.0'' v.c
Input/Output section Input signal bal/unbal
Input connectors XLR
Output connectors XLR
Input sensitivity -2 dBu/+4 dBu
Processor section Crossover Frequencies Selectable
Protections Thermal, Excurs., RMS
Limiter Soft Limiter
Controls Xover, Phase switch, Deep/Punch, Output Delay Setting
Power section Total Power 4400 W Peak
Low frequencies 4400 W Peak
Cooling Convection/Forced
Connections Powercon TRUE1 TOP IN/OUT
Standard compliance Safety agency CE compliant
Physical specifications Cabinet/Case Material Plywood
Hardware 2 x M20
Handles 2 x side
Pole mount/Cap M20 thread
Grille Steel
Color Black
Size / Weight Height 550 mm / 21.65 inches
Width 1180 mm / 46.46 inches
Depth 700 mm / 27.56 inches
Weight 80 kg / 176.37 lbs
