Product details

More Information
Key Features
  • One microphone preamp
  • One dedicated instrument input
  • Two Air preamp modes for classic console sound
  • Includes Hitmaker Expansion software bundle
  • Plus Pro Tools Intro+, Ableton Live Lite, and Cubase LE
Technical Specifications

Specifications

Overview

  • Number of Microphone Preamps 1
  • Phantom Power Yes
  • Instrument Inputs 1
  • Line Inputs 1
  • Air Mode Yes
  • Line Outputs 2
  • Headphone Outputs 1
  • Loopback Yes
  • Connectivity USB Type-C
  • Protocol USB 2.0
  • Form Factor Desktop
  • Simultaneous I/O4 x 2 (including Loopback inputs)
  • A/D Resolution 24-bit/192 kHz
  • Bus Powered Yes (900mA)

Dimensions

  • Height 46.5mm
  • Width 143mm
  • Depth 96mm
  • Weight 0.382kg

Supported sample rates

  • 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

Microphone inputs

  • Frequency Response20-20kHz ± 0.06dB
  • Dynamic Range113dB (A-Weighted)
  • THD+N-100dB @ minimum gain
  • Noise EIN-127dBu (A-Weighted)
  • Maximum Input Level9.5dBu
  • Gain Range57dB
  • Impedance3kΩ

Line inputs

  • Frequency Response20-20kHz ± 0.05dB
  • Dynamic Range113dB (A-Weighted)
  • THD+N-100dB @ minimum gain
  • Maximum Input Level22dBu
  • Gain Range57dB
  • Impedance60kΩ
