Product details

More Information
Key Features
  • Two ultra-low-noise mic/line/instrument preamps
  • Two additional line inputs
  • Two Air preamp modes for classic console sound
  • Clip Safe and Auto Gain modes
  • MIDI In and Out
  • Includes Hitmaker Expansion software bundle
  • Plus Pro Tools Intro+, Ableton Live Lite, and Cubase LE
Technical Specifications

Specifications

Overview

  • Number of Microphone Preamps2
  • Phantom PowerYes
  • Instrument Inputs2
  • Line Inputs4
  • Air ModeYes
  • Auto GainYes
  • Clip SafeYes
  • Line Outputs4
  • Headphone Outputs1
  • LoopbackYes
  • MIDIYes
  • ConnectivityUSB Type-C
  • ProtocolUSB 2.0
  • Form FactorDesktop
  • Simultaneous I/O6 x 6 (including Loopback inputs)
  • A/D Resolution24-bit/192 kHz
  • Bus PoweredYes (1.5A)

Dimensions

  • Height60mm
  • Width180mm
  • Depth130mm
  • Weight0.798kg

Supported sample rates

  • 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

Microphone inputs

  • Frequency Response20-20kHz ± 0.06dB
  • Dynamic Range116dB (A-Weighted)
  • THD+N-100dB @ 8dB gain
  • Noise EIN-127dBu (A-Weighted)
  • Maximum Input Level16dBu
  • Gain Range69dB
  • Impedance3kΩ

Variable Line inputs

  • Frequency Response20-20kHz ± 0.05dB
  • Dynamic Range115.5dB (A-Weighted)
  • THD+N-100dB @ 8dB gain
  • Maximum Input Level22dBu
  • Gain Range69dB
  • Impedance60kΩ

Fixed Line inputs

  • Frequency Response20-20kHz ± 0.02dB
  • Dynamic Range115.5dB (A-Weighted)
  • THD+N-105dB
  • Maximum Input Level22dBu
  • Impedance60kΩ
