Key Features
  • Two ultra-low-noise mic preamps with front-panel line/instrument inputs
  • Two Air preamp modes for classic console sound
  • Auto Gain and Clip Safe modes
  • Includes Hitmaker Expansion software bundle
  • Plus Pro Tools Intro+, Ableton Live Lite, and Cubase LE
Technical Specifications

Specifications

Overview

  • Number of Microphone Preamps 2
  • Phantom Power Yes
  • Instrument Inputs 2
  • Line Inputs 2
  • Air Mode Yes
  • Auto Gain Yes
  • Clip Safe Yes
  • Line Outputs 2
  • Headphone Outputs 1
  • Loop back Yes
  • Connectivity USB Type-C
  • Protocol USB 2.0
  • Form Factor Desktop
  • Simultaneous I/O4 x 2 (including Loopback inputs)
  • A/D Resolution24-bit/192 kHz
  • Bus Powered Yes (900mA)

Dimensions

  • Height47.5mm
  • Width180mm
  • Depth117mm
  • Weight0.595kg

Supported sample rates

  • 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

Microphone inputs

  • Frequency Response20-20kHz ± 0.06dB
  • Dynamic Range116dB (A-Weighted)
  • THD+N-100dB @ 8dB gain
  • Noise EIN-127dBu (A-Weighted)
  • Maximum Input Level16dBu
  • Gain Range69dB
  • Impedance3kΩ

Line inputs

  • Frequency Response20-20kHz ± 0.05dB
  • Dynamic Range115.5dB (A-Weighted)
  • THD+N-100dB @ 8dB gain
  • Maximum Input Level22dBu
  • Gain Range69dB
  • Impedance60kΩ
