Product details

More Information
  • 2-way, bi-amplified, bass reflex design
  • Biamped: 700W RMS LF and 200W RMS HF power amplifiers in Class D for LF and in Class H/AB for HF
  • Digital Signal Processor with graphic display
  • 15 mm (0.59") birch plywood scratch resistant enclosure and internal bracing
  • High efficiency switch mode power supply
  • Control Panel features balanced XLR/Jack input, XLR LINK OUT, 2 x Volume, RCA Stereo input, DSP display with rotative encoder and push
  • 320mm (12") LF woofer with 64mm (2.5") voice coil, custom made for FBT
  • 25mm (1") exit throat B&C HF compression driver with 36mm (1.4") voice coil
  • Frequency response from 48Hz to 20 kHz
  • 80°H x 50°V Constant Directivity Rotatable Horn
  • 6 x M10 suspension points, optional wall bracket mount thread, 35mm (1 3/8") top-hat
  • Speaker stand socket, two aluminium handles
  • 45° monitor taper
  • Adjustable delay between 0 - 10m
  • Weight : 20.6Kg
  • Dimensions : 387 x 665 x 380mm
Technical Specifications
  • Configuration: 2 Way
  • Frequency Response: 42Hz – 20kHz (-6dB)
  • Low Frequency Woofer: 12" / 2.5" Coil
  • High Frequency Driver: 1" / 1.4" Coil
  • Maximum SPL Continuous/Peak: 126 / 133dB
  • Dispersion (HxV): 80° x 50° Rotatable
  • Input Impedance: 22 kOhm
  • Input Connector: XLR/Jack Combo Socket with XLR Link Out, RCA Stereo Input
  • Net Dimension (WxHxD): 387 x 665 x 380 mm
  • Net Weight: 20.6 kg
  • Transport Dimension (WxHxD): 500 x 765 x 470 mm
  • Transport Weight: 23.1 kg
  • AC Power Requirements: 640VA
  • Built-in Amplifier LF/HF: 900W (700W LF + 200W HF)
  • Built-in Amplifier Peak LF/HF: 1800W (1400W LF + 400W HF)
  • Power Cord: 5m Neutrik True1
