Product details

More Information


• Multipurpose 8” coaxial, 450W-8Ohm / 124dB SPL
• 8” coaxial woofer with 2” coil
• 1” HF driver with 1.4” coil on conical 90° horn
• 100V line transformer with selectable 100W-50W power tapping
• Sturdy molded polyethylene curved enclosure
• Stainless steel U bracket and other included hardware accessories
• 4 wires cable to select the desired power tapping
• Water-stop grille with 3 layers of protection
• IP55 weather resistant
• Standard grey finish RAL 7011

Technical Specifications
  • Code: RAL 7011 / 36193
  • Configuration: 2 Coaxial Way
  • Low Frequency Woofer: 8", 2" Coil
  • High Frequency Driver: 1", 1.4" Coil
  • Transformer: 100V / 70V / 100W - 50W
  • Frequency Response (-6dB): 80Hz - 20kHz
  • Sensitivity (@1W/1m): 95dB
  • Maximum SPL (Cont./Peak): 120dB / 124dB
  • Dispersion: 90° Conical
  • Crossover Frequency: 1.8kHz
  • Recommended HP Filter: 60Hz - 24dB/Oct
  • Recommended Amplifier: 450W RMS
  • Long Term Power: 225W
  • Short Term Power (IEC 268-5): 900W
  • Nominal Impedance: 8 Ohm
  • Material Cabinet: Polyethylene
  • Material Grille: Stainless Steel
  • Net Dimensions (W x H x D): 317 x 285 x 316mm / 12.48" x 11.22" x 12.44"
  • Transport Dimensions (W x H x D): 395 x 390 x 340mm / 15.55" x 15.35" x 13.38"
  • Net Weight: 10.50kg / 23.14lb
  • Transport Weight: 12.20kg / 26.89lb
  • Input Connectors: 4 Wire Cable
