Product details

More Information
  • Stylish architectural cabinet design
  • Acoustically transparent steel grilles with protection cloth
  • High SPL, fast responding dynamics, excellent intelligibility, wide band, extremely low distortion
  • Baltic birch plywood cabinets available in black or white extra texture paint
  • Choice of different RAL paint colours on order
  • Choice of different paint finish: glossy, matt, textured and more, on order
  • Custom designed low frequency woofers, made in Italy
  • Custom designed high frequency compression drivers, made in Italy
  • Rotatable horns for optimal horizontal or vertical sound dispersion angle
  • Selectable bi-amp/full range crossover network
  • Full suspension possibilities through multiple M10 / M5 threaded rigging points and a wide range of mounting hardware
  • Possibility to install line transformers for 100V/70V applications
  • Possibility to order weatherproof versions for outdoor use
  • Possibility to extend low frequencies performance through dedicated and compact subwoofers (Archon 208S, Archon 215S)
Technical Specifications
  • Configuration: 1 Way
  • Frequency Response: 50Hz – 500Hz
  • Low Frequency Woofer: 2 x 8" with 2" VC
  • Maximum SPL Cont/Peak: 129 / 132dB
  • Dispersion: Omnidirectional
  • Input Impedance: 8 Ohm
  • Crossover Frequency: External Active Required
  • Input Connector: 2 x Speakon NL4 In & Thru
  • Net Dimension (WxHxD): 550 x 285 x 480 mm / 21.65 x 11.22 x 18.89 inch
  • Net Weight: 18 kg / 39.6 lb
  • Transport Dimension (WxHxD): 690 x 370 x 625 mm / 27.16 x 14.56 x 24.60 inch
  • Transport Weight: 20 kg / 44 lb
