Allen & Heath ZEDi-8 8-channel Mixer Features:

  • Rugged compact mixer with two mono channels, two stereo channels, and USB recording/playback
  • 2-in/2-out USB 2.0 interface supports 24-bit/96kHz audio quality
  • Includes Cubase LE DAW software for Mac/PC, and Cubasis LE app for iOS
  • GSPre mic preamps offer high headroom and low noise floor
  • Connect guitars and basses without separate DI boxes thanks to switchable hi-Z inputs
  • Low-cut filters to reduce rumble and other unwanted low frequencies
  • Effective sound shaping from 2-band EQs
  • Channels can be individually assigned to the headphone mix
  • XLR outputs for studio monitors or powered PA speakers
  • Smooth 60mm fader for controlling your main mix
  • Rotary controls are secured to the faceplate with steel nuts for maximum durability

The Allen & Heath ZEDi-8 mixer is a great value for studio or stage use.

Technical Specifications
Tech Specs
  • Type:Analog mixer with USB interface
  • Channels:8
  • Computer Connectivity:USB (2 x 2)
  • Faders:1 x 60mm Main Mix fader
  • Inputs - Mic Preamps:2
  • Phantom Power:2
  • Inputs - Line:2 x 1/4" TRS (line/instrument)
  • Inputs - Other:4 x 1/4" TRS (stereo paired)
  • Outputs - Main:2 x XLR (left, right)
  • Headphones:1 x 1/4"
  • USB:1 x Type B
  • EQ Bands:2-band EQ
  • Software:Cubase LE (included)
  • Height:3.5"
  • Width:9.8"
  • Depth:9.3"
  • Weight:3 lbs.
  • Manufacturer Part Number:AH-ZEDi8
