MACKIE MIX 12 FX

MACKIE MIX 12 FX

The midsize Mackie Mix12FX desktop audio mixer offers you the full-scale functions and the quality everyone here at Sweetwater has come to expect from Mackie. Four microphone preamplifiers with switchable phantom power, 3-band EQs, and 75Hz highpass filters accommodate a wide range of mics and mixing conditions. Another four stereo channels let you connect keyboards, media players, and other line-level gear. Each channel also comes with an FX send, which lets you tap into Mix12FX's effects processor. Twelve onboard digital effects make it easy to add reverb to vocals, depth to drums, or atmosphere across your mix.

More Information

  • A high-performance, 12-input desktop mixer with onboard effects
  • 4 mic/line input channels includes switchable phantom power
  • Each mono channel also features a 3-band EQ and highpass filtering
  • 4 stereo channels offer a choice of balanced and unbalance line input for
  • FX send on each channel lets you pass signal to the dedicated effects processor
  • 12 onboard effects let you add space, depth, and dimension to your mix
  • Tape RCA I/O offers additional signal routing options
  • Separate Main Mix and Headphones/CR volumes provide added mixing flexibility
  • Built to Mackie's toughness standards for portable use

Technical Specification

  • Type:Analog
  • Channels:12
  • Inputs - Mic Preamps:4 x XLR
  • Phantom Power:4 Channels
  • Inputs - Line:12 x TRS, 1 x stereo RCA
  • Outputs - Main:2 x TRS
  • Outputs - Other:1 x stereo RCA (Tape), 2 x TRS (Control Room)
  • Aux Sends:1 x Post
  • Send/Return I/O:1 x TRS (FX Send)
  • Headphones:1 x 1/4
  • "EQ Bands:3-band
  • Effects:Yes
  • Height:2.1"
  • Width:11.7"
  • Depth:9.6"
  • Weight:3.7 lbs.
  • Manufacturer Part Number:2044096-00
