SM PROFESSIONAL PA 2.0

•  Professional high-power amplifiers.

•  Input: Balanced XLR and 1/4” Stereo Jack.

•  3 switchable operational modes: Stereo, Mono & Bridge.

•  High-current toroidal transformers with high-grade cores for greater transient response & low-noise even at 2 Ohms.

•  High quality glass epoxy, double-sided PTH PCB’s & high-grade components ensures reliability in even tough ambient environs.

•  Intelligent cooling using low-noise variable speed fans & direct mounted over-designed heat-sinks.

•  Sensitivity (0dB or+4 dB) selection switch allows flexibility in connection of input sources.

•  Switchable Low-cut switch for protection & tight-low end performance.

•  Switchable Limiter Switch to protects speakers from damage due to distorted input signals.

•  41-detent rotary volume knobs.

•  Mute, Signal, Clip and fault LED indicators assists you to monitor performance.

•  Rated for 2 Ohms operation.

POWER OUTPUT-

2 Ω (True RMS),20Hz-20kHz,1% THD:2 x 1000 W

2 Ω (EIA), 1kHz , 1%THD:2 x 2250 W

4 Ω (True RMS),20Hz-20kHz,1% THD:2 x 800 W

4 Ω (EIA), 1kHz , 1%THD:2 x 1380 W

8 Ω (True RMS),20Hz-20kHz,1% THD:2 x 500 W

8 Ω (EIA), 1kHz , 1%THD:2 x 755 W

BRIDGED MODE-

4 Ω (True RMS),20Hz-20kHz,1% THD_:2000 W

4 Ω (EIA), 1kHz , 1%THD_:4500 W

8 Ω (T rue RMS),20Hz-20kHz,1% THD:1600 W

8 Ω (EIA), 1kHz , 1%THD_:2760 W

Damping factor (8 Ω):> 200 :1

Frequency Response:20Hz – 20kHz (±0.5dB)

Protection Devices:Temperature, DC, RFI Short Circuit, Soft-Start, Over load

Input Connector (Per CH.):XLR, 1/4” TRS Jack

Output Connector (Per CH.):Speakon Connector

Dimensions (WxDxH)mm:482 x 455 x 88 (2U)

Net Weight (Kgs.):19
