POWERX PRO D LINE 3000

POWERX PRO D LINE 3000

Experience the pinnacle of audio excellence with PowerX Pro's D-LINE series amplifiers, designed to deliver unparalleled sound quality and reliability. Engineered for professionals and audiophiles alike, these amplifiers boast impressive power output, advanced features, and robust construction. With three models to choose from - D LINE 5000, D LINE 4000, and D LINE 3000 - you can select the perfect amplifier to suit your specific needs and elevate your audio experience to new heights.

More Information

POWER:
- 8 ohms stereo power: 650w x 2
- 4 ohms stereo power: 1000w x 2
- 2 ohms stereo power: 1300w x 2
- 8 ohms bridge power: 2000w
- 4 ohms bridge power: 2600w

FUNCTION:
- Front Panel Indicator: Working state, Voltage, Clip limit, Temp, Prot
- Rear Panel Indicator: Parallel / Bridge selector indicator
- Front Panel: Power switch, volume control knob
- Rear Panel: Stereo / parallel / Bridge mode selector switch, Sensitivity selector switch

Technical Specification

OTHER SPECIFICATIONS:
- Frequency Response: 20Hz - 20 KHz (±0/-1.5 dB)
- THD+N: <0.5%
- S/N rate: >90dB
- Damping Factor: >300
- Crosstalk: >65dB
- Slew Rate: >10V/us
- Input Sensitivity (bal/unbal): 0.775V/1 V/32 dB
- Input Impedance (bal/unbal): 20k ohms / 10k ohms
- Voltage Gain (8 ohms): 39.3dB
- Output Circuitry: Class 1
- Cooling: Air flow from front to rear
- Protection: Soft start DC short circuit over load clip limit over heat progressive volume VHF
CONNECTOR:
- Input: Balance input XLR - F
- Output: NL 4 SPEAKON Nutrik™

DIMENSION / WEIGHT:
- Product Dimension (mm): 483 x 451 x 89
- Packing Dimension (mm): 595 x 565 x 170
- GW (±2.5 Kg): 20Kg
- Power supply: Non removable IEC power cord AC 240v / 50 Hz ±10
