Yamaha QL1

Yamaha QL1

The Quintessential Compact

The acclaimed CL series raised live digital mixing console performance to an unprecedented level of refinement with evolved sound quality, operability, and functionality, while maintaining the traditional values that have made Yamaha digital mixers industry standards. Core features and performance inherited directly from the CL series, including natural sound supported by sonically superb internal processing capabilities, operation that easily adapts to the demands of just about any working environment, and built-in Dante networking that facilitates flexible system configuration, have now been condensed and concentrated into the compact QL series digital mixing consoles. QL series consoles offer all-in-one mixing, processing, and routing capability for small to medium scale live sound, corporate speech events, installations, and much more.

More Information

Yamaha QL1 Digital Mixer Features:

  • Premium internal processors simulate classic studio gear and more
  • Rupert Neve-designed EQ and dynamics for studio-quality sound
  • Automixing functionality via the Dan Dugan automatic mixer
  • Dante network support lets you create complex system designs
  • Remote control via tablet or computer lets you go deep into your mix
  • Tons of scene memory, customization options, and more

Technical Specification

Tech Specs

  • Type:Digital
  • Channels:32 mono, 8 stereo mixing channels
  • Inputs - Mic Preamps:16 x XLR
  • Phantom Power:16 x Channels
  • Outputs - Main:8 x XLR (Omni)
  • Inputs - Digital:2 x EtherCon Cat5 (Dante Primary, Secondary)
  • Outputs - Digital:1 x XLR (AES/EBU), 2 x EtherCon Cat5 (Dante Primary, Secondary)
  • Busses/Groups:16 mix, 8 matrix
  • Inserts:Yes
  • Talkback:Yes
  • MIDI I/O:In, Out
  • Data I/O:Network RJ-45, GPI
  • Headphones:1 x 1/4"
  • USB:1 x Type A
  • I/O Expansion Slots:2 x Slots (mini-YGDAI)
  • Word Clock:In, Out
  • Faders:18 x 100mm Throw
  • EQ Bands:4-band Parametric
  • Effects:Yes
  • Rackmountable:Yes (kit sold separately)
  • Height:10.7"
  • Depth:22.1"
  • Width:18.4"
  • Weight:32.4 lbs.
