DYNATECH HP 7000

DYNATECH HP 7000

Dynatech's HP-7000 power amplifiers are built around robust and advanced toroidal transformers, and deliver clean power on demand. The advanced protection circuitry guards against short circuit, over load, clip limit, peak current limit, over heat and open circuit, and also protects against ultrasonic and RF interference.

More Information

A high current power supply increases reliability and performance. Other features include center-detented gain controls, input peak limiter and fast recovery to ensure low distortion. The variable speed fans effectively cool the amp and protect against overheating. Input is through XLR or 1/4" connectors, while you can use Speakon-type or binding post connectors for output.

Dynatech HP-7000 Amplifiers are specially designed for professionals who value high power, audio clarity, reliability and lasting performance.

Technical Specification



 MODEL   HP-7000
  Output Power
  8Ω stereo 1450W x 2
  4Ω stereo 2250W x 2
  2Ω stereo 3600W x 2
  8Ω bridge 4500W
  4Ω bridge 7200W
  Other Specifications
  Frequency Response 20Hz-20kHz, +0/-0.5dB
  THD+N <0.5%
  S/N rate (A Weighted) ≥96dB
  Damping Factor >1200
  Crosstalk ≥60dB
  Slew rate >40V/µs
  Input sensitivity 0.775V/1V/32dB
  Input impedance (bal/unbal) 20kΩ/10kΩ
  Voltage gain 43.4dB
  Cooling Air flow from front to rear
  Protection Soft start, VHF, DC, short circuit, over load, clip limit, peak current limit
over heat, progressive volume
  Connection
  Input Balance input XLR-F, Balance output XLR-M
  Output Two red and black binding posts. NL4 speakon
  Function
  Front panel indicator Rock power switch / independent channel volume control knob/ power indicator /
signal indicator / clipping indicator / protection instructions
  Rear panel indicator Stereo/parallel/bridge mode selector switch, sensitivity selector switch, soft cut switch
  Dimensions / Weight
  Product dimension (mm) 483 x 503 x 133 (3U)
  Packaging dimension (mm) 620 x 585 x 210 (3U)
  Net weight 36.8 kgs
  Gross weight 40 kgs
